systemd-sysext activates/deactivates system extension images. […] (man systemd-sysext)

Overview

Systemd systemd-sysext merges system extension images (we will refer to them as extension images from here on) into the OS root fs via OverlayFS.

Extension images are files and directories provided in one of the following format:

  • plain directories
  • btrfs subvolumes
  • fs images (squasfh, ext4, erofs, …)
  • GPT partition images

The only paths that are merged from the folders and files present in the extension images are /usr and /opt. These two paths become read-only 1 on the merged fs, also if they were mutable (rw) in the base OS fs.

All files in the extension images are made available instantly and atomically.

Extension images must be placed in:

  • /etc/extensions/
  • /run/extensions/
  • /var/lib/extensions/

Basic Usage

systemd-sysext refresh [--force]

This will check the extension image folders, unmerge all the images and freshly merge all the available ones. The /usr and /opt dir, if present in one of the extension images, will become read-only (if they weren’t yet).

systemd-sysext merge [--force]

Merges available extensions images. If some extension images are already merged and new extension images are detected the command fails (requires a systemd-sysext unmerge first).

systemd-sysext unmerge

Unmerges all the currently merged extension images.

ℹ️ Note

Systemd provides also the systemd-sysext.service unit file to activate the available extension images.

Compatibility Enforcement

Each extension image requires a paired extension-release file containing information about its ompatibility.

The extension-release file must match the image NAME: so, an extension image called NAME.raw requires an extension-release file /usr/lib/extension-release.d/extension-release.NAME.

The extension-release file is compared with the host os-release file (/etc/os-release).

The mandatory fields that have to match are:

  • ID
  • either SYSEXT_LEVEL or VERSION_ID

otherwise the extension image will not be merged.

You can disable the compatibility check by:

  • using ID=_any in the extension-release file
  • using the --force flag with the systemd-sysext merge or refresh commands

Systemd units in extension images

If systemd unit files are shipped inside the extension image, the service manager needs to be reloaded in order to detect them. This can be achieved adding the field EXTENSION_RELOAD_MANAGER=1 in the extension-release file.

💡 Tip

Systemd unit files included in extension images are not started also if loaded at boot by the systemd-sysext service as the unit files become available too late.

The Flatcar project solves the issue by providing the ensure-sysext service which triggers systemd to reload and restart the service files after the system-sysext service has merged the available extension images.

systemd-confext

The systemd-confext tools is similar to systemd-sysext but targets extension images for configuration files (it merges the /etc path).

Exec permission is disabled (by default).

systemd-confexts extension images should be placed in one of:

  • /run/confexts
  • /var/lib/confexts
  • /usr/lib/confexts
  • /usr/local/lib/confexts

🔧 Debugging

systemd-dissect [--list] $NAME.raw

Use systemd-dissect to check the extension image file properties.

To debug systemd-sysext commands, prepend (or export) SYSTEMD_LOG_LEVEL=debug.

  1. Actually, the images can be merged rw specifying the --mutable=[no, auto, yes, import, ephemeral, ephemeral-import] option ↩︎
