mkosi (make operating system image) is a powerful tool to generate OS fs images.

It allows to pick a distribution and build the OS fs image starting from the available packages there.

When targeting an opensuse distro, it retrieves the files and folders packaged in the distro rpm by acting as a zypper --buildroot wrapper.

For an overall overview and introduction of the tool see the A re-introduction to mkosi – A Tool for Generating OS Images blogpost from Daan De Meyer.

Here we will assume basic knowledge of the tool and will focus on building System Extension Images.

Format=sysext Output

mkosi allows to directly specify a sysext format output in the config file.

The sysext image must be built on top of a base image.

As an example, let’s build a system extension image from the helm package from OpenSUSE Tumbleweed:

mkosi.conf

[Distribution]
Distribution=opensuse
Release=tumbleweed
[Output]
OutputDirectory=mkosi.output
[Build]
CacheDirectory=mkosi.cache
[Validation]
Verity=no

mkosi.images/base/mkosi.conf

[Output]
Format=directory
[Content]
Packages=
 systemd
 udev

mkosi.images/helm/mkosi.conf

[Config]
Dependencies=base
[Output]
Format=sysext
Overlay=yes
[Validation]
Verity=no
[Content]
BaseTrees=%O/base
Packages=helm

running mkosi in the base dir triggers the creation of the base image (we picked up a a plain directory format there as we don’t really need an image for it) and the creation of the helm system extension image.

The generated artifacts are made available in the mkosi.output directory.

ℹ️ Note

The sysext format is an automated and opinionated way to build a system extension disk image. Inspecting the mkosi.output/helm.raw image (see debugging in systemd-sysext notes) you can see that mkosi created:

  • a GTP partition containing a single partition formatted with an erofs file system
  • a /usr/lib/extension-release.d/extension-release.helm file matching ID and ARCHITECTURE from the /etc/os-release of the base image

Custom System Extension Image

If the desired system extension image requires a different file system than the erofs one or a customized partitioning is needed, a normal disk format should be specified in the mkosi configuration file and the required configurations (the extension-release file and the systemd-repart configuration) should be provided explicitly.

💡 Tip

The partitioning configuration must be specified in the mkosi.repart subfolder. Additional files and folders to be copied in the final image should be put into the mkosi.extra folder.

Let’s provide an example configuration for a system extension image for our helm package from OpenSUSE Tumbleweed: this time we want it packed in a squashfs file system and we want the extesion-release file to carry a ID=_any value to make the image compatible with multiple linux systems:

mkosi.conf (stays the same)

Distribution]
Distribution=opensuse
Release=tumbleweed
[Output]
OutputDirectory=mkosi.output
[Build]
CacheDirectory=mkosi.cache
[Validation]
Verity=no

mkosi.images/base/mkosi.conf (stays the same too)

[Output]
Format=directory
[Content]
Packages=
 systemd
 udev

mkosi.images/helm/mkosi.conf

[Config]
Dependencies=base
[Output]
Format=disk
Overlay=yes
[Validation]
Verity=no
[Content]
BaseTrees=%O/base
Packages=helm

mkosi.images/helm/mkosi.extra/usr/lib/extension-release.d/extension-release.helm (new)

ID=_any
ARCHITECTURE=x86-64

mkosi.images/helm/mkosi.repart/root.conf (new)

[Partition]
Type=root
Format=squashfs
CopyFiles=/opt/
CopyFiles=/usr/
Minimize=best

Note that we changed the Format to disk in the mkosi configuration file for the helm image, so we had also to specify ourselves the extension-release.helm file required for an extension image.

💡 Update

Actually the default partition fs (erofs) comes from systemd-repart, used by mkosi under the hood. To change systemd-repart default fs it is enough to set the SYSTEMD_REPART_OVERRIDE_FSTYPE_ROOT environment variable to the desired fs type. This could be achieved in the [Build] section of the mkosi configuration:

[Build]
Environment=SYSTEMD_REPART_OVERRIDE_FSTYPE_ROOT=squashfs

example available on 🔗github

📄 Daan De Meyer’s mkosi blogpost

🎬 Daan De Meyer’s mkosi talk at All Systems Go! conference

💾 mkosi project

💾 mkosi example
